Wedge Type Tension Clamp

• High Load Capacity: Suitable for 35–70 mm² overhead cables, with 12 KN safe load, ensuring stability in any high-load scenario.
• Quick Installation: Self-locking wedge design, no additional tools required, saving installation time and improving efficiency.
• Wide Temperature Adaptation: –40 °C ~ +120 °C ensures stable operation in all seasonal and environmental conditions.
• Extreme Weather Stability: Resistant to wind, rain, UV, and corrosion, ideal for coastal, desert, and cold regions.
• Flexible Installation: Compatible with end and mid-span mounting, adaptable to various line layouts.
• Long Service Life: Durable materials reduce maintenance frequency, ensuring ≥25 years of reliable operation.

Note: wedge type tension clamp is designed to maintain efficient installation and safe operation under complex layouts and high-load conditions.

PRODUCT INSTALLATIONI DISPLAY

For fixing ADSS (up to 100 m) cables.



Anchor the clamp on the pole.
Push the wedge in the clamp:tighten the wedge to fixthe cable.

Hand-pull the wedge toverify the cable doesn't slip out.
Examine the clamp is secure by observing the wedge position.

Locating the clamp is secure by observing thewedge position.


• Confirm conductor size is 35–70 mm².
• Place the cable into the clamp body and ensure self-locking wedge engagement.
• Fix the clamp onto the pole or support point using standard tools or the self-locking design.
• Check tension distribution to avoid local overload.
• For high or complex locations, auxiliary installation fixtures can enhance safety.

• End and mid-span fixation of large cross-section overhead cables, ensuring urban and industrial line stability.
• Urban low-voltage distribution lines, maintaining stability under high load.
• Industrial park high-load lines, suitable for complex layouts and large conductors.
• Renewable energy plants and rail transit lines, ensuring long-term stability of large cross-section lines.
• Extreme outdoor conditions, such as typhoons, heavy snow, or strong UV areas.
• Performs well in coastal, desert, cold, and windy-sandy regions.
• Compatible with various supporting accessories for flexible layout.
• Wedge type tension clamp easily adapts to multiple construction scenarios, improving project efficiency and safety.

• Vietnam industrial park upgrade: Wedge tension clamp provides reliable fixation, +30% installation efficiency, –50% maintenance frequency.
• Philippines solar PV project: Lines remain stable under high temperature and strong wind, reducing power outages.

• Middle East low-voltage renovation: Self-locking wedge supports large conductors, +35% line safety, shortened construction cycle.
• Wedge type tension clamp gains consistent praise through standardized design and multifunctional adaptability.

• Field operators report smoother handling, reduced risks, and improved efficiency.

• 15+ years of experience in overhead line accessories, with rich R&D and project experience.
• Complete mold development and testing capabilities, ensuring accurate dimensions and stable performance.
• Export to 50+ countries annually, recognized in multiple projects.
• One-on-one technical support, providing on-site guidance.
• Customizable solutions to meet different line types and environmental requirements.
• Quick project response and one-stop technical services from design to installation.

• ISO 9001 quality management system certified, fully controlled production process.
• EN 50483 and IEC 61284 tested, verified for tension, weather resistance, and impact.
• SGS, TÜV third-party certification ensures reliability.
• Product traceable, each unit has a unique code.
• Materials strictly selected for excellent durability and mechanical performance.

• CE - European safety standard.
• RoHS - Free of harmful substances, environmentally safe.
• ISO 9001:2015 quality management system.
• Multiple certifications ensure reliability in domestic and international markets.

• Customize conductor size and load rating for optimal line adaptation.
• OEM/ODM laser engraving and moldable logo to meet branding and project requirements.
• Tailored solutions for different layouts and environmental conditions.
• Enhanced weather-resistant or high-load versions available for extreme conditions.

• Inner moisture-proof bag + outer five-layer carton + pallet fixation.
• Neutral or custom packaging available.
• Complete export documentation: CO, packing list, invoice.
• Flexible shipping: sea, air, express.
• Delivery lead time: stock 7 days / custom 10–15 days.
• Special packaging provides shockproof, moisture-proof, and pressure resistance.

• Tension test (12 KN) ensures each batch meets safe load.
• Salt spray test (1000 hours) verifies corrosion resistance.
• UV aging test (2000 hours) guarantees outdoor reliability.
• Impact and temperature cycle tests ensure stability under extreme conditions.
• Full inspection reports provide transparency.
• Random batch checks ensure long-term stability.

• Reduced maintenance: Strong weather resistance, long service life.
• Enhanced line safety: High load capacity and safe insulation.
• Quick installation: Self-locking wedge design, no tools needed.
• Extreme environment adaptability: Typhoon, snow, high temperature.
• Improved project efficiency: Less downtime and maintenance.
• Multi-scenario adaptation: Various accessories for complex layouts.

• Electrical distribution anchor clamp
• Plastic Anchor Clamp
• Anchoring tension clamp
• Dead End Clamp for ABC Cable

Choose different types based on conductor size and construction scenario for cross-project application, improving efficiency and safety.
