Technical Specifications
|
Model |
Applicable Nominal Cross-Section of Aerial Insulated Aluminum Stranded Conductors (mm²) |
Stripping Length (mm) |
Main Dimensions (mm) |
Nominal Breaking Load (kN) |
Material |
|||
|
L |
φ |
R |
B |
|||||
|
NXL-1 |
JKLYK-10, 35~50 |
225 |
145 |
18 |
5 |
16 |
7.4 |
Aluminum Alloy |
|
NXL-2 |
JKLYK-10, 70~95 |
245 |
155 |
18 |
6 |
16 |
14.5 |
Aluminum Alloy |
|
NXL-3 |
JKLYK-10, 120~150 |
255 |
165 |
18 |
8.5 |
16 |
22.1 |
Aluminum Alloy |
|
NXL-4 |
JKLYK-10, 185~240 |
300 |
190 |
18 |
11 |
18 |
36.4 |
Aluminum Alloy |
|
Model |
Applicable Conductor Cross-Section (mm²) |
Grip Strength (kN) |
Nominal Breaking Load (kN) |
Remarks |
|
|
10kV |
20kV |
||||
|
NXL-2J |
35~70 |
25~35 |
6.7 |
10.8 |
Suitable for insulated aluminum conductors |
|
NXL-3J |
95~150 |
50~95 |
13.7 |
22.5 |
Suitable for insulated aluminum conductors |
|
NXL-4J |
185~240 |
120~150 |
22.5 |
36.5 |
Suitable for insulated aluminum conductors |
Product Introduction
Materials of Wedge Insulation Strain Clamp
- Materials: The main body is made of non-magnetic, high-strength, oxidation-resistant aluminum alloy, which eliminates hysteresis loss, saves energy, and reduces consumption, meeting the requirements for aluminum-to-aluminum contact in aluminum conductors; the accompanying insulating cover is made of weather-resistant insulating material, and the fasteners are made of hot-dip galvanized high-strength steel for rust and corrosion resistance; all metal components undergo anti-corrosion treatment to extend outdoor service life.
Installation Steps
Direct from the manufacturer, great value for money.
Thread the wire through the clamp body and insert the wedge core, ensuring the
wedge core fits snugly against the wire and is flush at both ends;
Use a tensioning tool to tighten the wire to the appropriate tension, then gently tap the end of the
wedge core to pre-tighten it, taking care not to damage the wire insulation;
Remove the tensioning tool and adjust the nut to meet project specifications;
Slide on the insulating sleeve to complete the insulation protection.
Precautions: The installation direction of the wedge core must align with the direction of force on the
wire to prevent the wire from slipping due to incorrect installation; sufficient length must be left at
the wire end, and the exposed portion must be treated to prevent strand separation; the insulating cover
must be installed properly to ensure a sealed protection. No complex modifications are required, allowing
for rapid deployment.
Why Choose Us
Please feel free to contact us with any inquiries.
Official certification, professional after sales service.
Certificate
Certificate
Certificate
Certificate
Certificate
Reliable Quality: Manufactured in strict compliance with national and industry standards, with comprehensive quality control throughout raw material inspection, production management, and finished product testing. Our products have passed authoritative certifications and are suitable for complex environments such as high-wind areas, ensuring quality assurance
High Adaptability: A complete range of models covering all specifications of conductors up to 10kV, with support for non-standard customization to meet diverse application needs, including terminal points, corners, and retrofit projects
High Cost-Effectiveness: Standardized production reduces costs; with no power loss, energy savings are achieved. Easy installation and low maintenance costs enhance project economic benefits
Comprehensive Service: We provide free technical consultation and product selection guidance. Customization requests are handled promptly, with convenient logistics, a robust warranty system, and timely after-sales support to ensure smooth project execution
Proven Capabilities: Equipped with advanced production facilities, a professional technical team, and a comprehensive testing system, we possess mass production capacity for rapid order fulfillment. With complete certifications, we are a trusted partner.
FAQ
Q:Are there third-party test reports for the products?
A:All standardized products come with type test reports and factory inspection reports. We can provide test certificates issued by national-level power testing institutions (such as the Electric Power Research Institute or the Quality Inspection Institute).
Q: What is the primary application of the NXL Wedge Insulation Strain Clamp?
A: It is primarily used on tension towers and angle towers in overhead transmission lines to anchor conductors or lightning arresters to tension insulator strings, bearing the full tension of the conductor.
Q: What does the NXL Wedge Insulation Strain Clamp model designation represent?
A: N stands for tension, X stands for wedge-type/wedge structure, and L stands for aluminum alloy material; it is a commonly used wedge-type aluminum alloy tension clamp.
Q: What types of conductors are NXL Wedge Insulation Strain Clamps suitable for?
A: They are suitable for steel-core aluminum stranded wire, aluminum stranded wire, aluminum alloy stranded wire, and certain types of steel stranded wire. Different models correspond to different conductor cross-sections.
